Generating Social Images with Remix

By Cameron McHenry on

SummarySocial images are a great way to enhance your website's online presence and Remix makes dynamically generating images for your website much simpler compared to other React frameworks.


Blog post: Generating Social Images with Remix by Cameron McHenry
The generated social image for this blog post (meta, right?)

Social images are an important part of every website's online presence, because it is typically the first thing that users or customers will see, before they even click on a link to your website. Adding a social image will help your website to stand out from others and provide additional information beyond just the title and URL.

The best social images are made by hand and carefully designed for every piece of content. Unfortunately, that is not practical for a large website or a site where the pages are dynamically generated. The most practical way is to dynamically generate social images from metadata.

React applications often have tons of dynamically generated pages, but many frameworks do not give us the level of control needed to generate social images dynamically, control caching, and embed them in the page via server-rendered HTML. So, services like Cloudinary are often used to fill this role.

But, Remix is not at all like other React frameworks.

Remix

Remix is a web application framework that gives you full control of the request and response pipeline, allowing you to write both server-side and client-side code simultaneously. It prerenders React components and serves it as plain HTML, allowing you to create a React application that potentially doesn't even include React as a client-side dependency!

For our purposes though, the important thing about Remix is that we can embed anything we want into the initial HTML page. This allows search engines and bots to crawl our websites and scrape the Open Graph image metadata tag.

Generating Social Images

To generate our social images, we will:

  1. Create a canvas using the node-canvas library
  2. Draw on it (title, author, profile image, etc.)
  3. Convert the canvas to a PNG

If you'd like to just copy and paste all of the code for this, I have created a GitHub Gist with all of the important code.

To install the canvas library, run:

npm install canvas

Next, let's write a type definition for all of the parameters in our image generation function.

type GenerateSocialImage = {
  // The name of the content.
  title: string;
  // Author name to display.
  author?: string;
  // Width of the social image.
  width?: number;
  // Height of the social image.
  height?: number;
  // Font size to use for the title and author name.
  fontSize?: number;
  // How much margin to leave around the edges of the image.
  margin?: number;
  // Path to the author profile image to display.
  profileImage?: string;
  // The radius of the author's profile image, if an image is supplied.
  profileRadius?: number;
  // The font to use for all text in the social image.
  font?: string;
};

Now, let's write a very simple image generation function. For these images, we are going to use dimensions of 1200x630.

import { createCanvas } from "canvas";

const generateImage = async ({
  width = 1200,
  height = 630,
}: GenerateSocialImage) => {
  const canvas = createCanvas(width, height);
  const ctx = canvas.getContext("2d");

  return canvas.toBuffer("image/png");
};

Cool. This function doesn't do much yet, but this is generating a blank 1200x630 canvas, getting a context for it (for drawing things), then converting it to a PNG image.

Adding Gradients

Let's add something interesting: background gradients.

const generateImage = async (/* ... */) => {
  // ...

  // Draw background gradient
  const gradient = ctx.createLinearGradient(0, width, width, height);
  gradient.addColorStop(0.3, "#6ee7b7");
  gradient.addColorStop(1, "#60A5FA");
  ctx.fillStyle = gradient;
  ctx.fillRect(0, 0, width, height);

  // ...
};

In this case, I've chosen the colors that I use for my website and hard-coded them, but you could easily add these as arguments to this function and supply different values. Here are some potential cool ideas to try:

  • Use different gradient colors for each author
  • Generate gradients based on page topic
  • Fade colors over time as post gets older relative to current date

Drawing the Title

Now, let's draw the most important thing: the title. Since titles can be longer than a few words, we will want to enable word wrapping. However, the canvas API does not specify word wrapping, so you will have to write your own.

Fortunately, others have already done some of the hard work of writing this code, so I have adapted this answer from Stack Overflow. Credit to the original authors there.

import { CanvasRenderingContext2D } from "canvas";

// Taken from: https://stackoverflow.com/a/16599668
const getLines = (
  ctx: CanvasRenderingContext2D,
  text: string,
  maxWidth: number
) => {
  const words = text.split(" ");
  const lines = [];
  let currentLine = words[0];

  for (let i = 1; i < words.length; i++) {
    const word = words[i];
    const width = ctx.measureText(currentLine + " " + word).width;
    if (width < maxWidth) {
      currentLine += " " + word;
    } else {
      lines.push(currentLine);
      currentLine = word;
    }
  }
  lines.push(currentLine);
  return lines;
};

Next, let's use the getLines function to wrap our title text, then iterate over the lines and draw the text:

const generateImage = async ({
  title,
  width = 1200,
  height = 630,
  fontSize = 80,
  margin = 60,
  font,
}: GenerateSocialImage) => {
  // ...

  // Calculate font sizes and metrics
  ctx.font = `bold ${fontSize}px ${font}`;
  const titleLines = getLines(ctx, title, width - margin * 2);
  const lineHeight = fontSize * 1.2;
  const textHeight = titleLines.length * lineHeight;

  // Draw title text
  titleLines
    .map((line, index) => ({
      text: line,
      x: margin,
      y: (height - textHeight) / 2 + index * lineHeight,
    }))
    .forEach(({ text, x, y }) => {
      ctx.fillStyle = "#000";
      ctx.fillText(text, x, y);
    });

  // ...
};

There's a lot of math and other processing going on here, but the gist of it is:

  • Set the font, then figure out which text should be wrapped
  • Calculate some metrics about the font and text, like line height and the total text height
  • For each line, draw it so that it is vertically centered in the image

If you'd like to position the title elsewhere, you can change the x and y properties inside the call to map.

Drawing the Author

Finally, many sites have authors associated with social images, so we will draw the author's name as well as their profile image in the social image.

import { loadImage, NodeCanvasRenderingContext2D } from "canvas";

const generateImage = async ({
  title,
  width = 1200,
  height = 630,
  fontSize = 80,
  margin = 60,
  profileImage,
  profileRadius = 120,
  author = "Cameron McHenry",
  font,
}: GenerateSocialImage) => {
  // ...

  // Vertical spacing after the title before drawing the author info
  const spacingAfterTitle = 50;
  // Where to start drawing author info
  const bottomOfTitleText = height / 2 + textHeight / 2 + spacingAfterTitle;
  // Height of the author name text, used for vertically centering with image
  const authorNameHeight = ctx.measureText(author).actualBoundingBoxAscent;

  // Draw the author's profile picture
  if (profileImage) {
    const img = await loadImage(profileImage);
    const x = margin;
    const y = bottomOfTitleText - profileRadius / 2;
    ctx.drawImage(img, x, y, profileRadius, profileRadius);
  }

  // ...
};

First, we calculate some positioning numbers that we will use to draw the author's image and name. Then, if there was a profile image displayed, we the load the image from the given path using loadImage and render it using ctx.drawImage.

Finally, we can render the author's name right next to the profile image:

const generateImage = async ({
  title,
  width = 1200,
  height = 630,
  fontSize = 80,
  margin = 60,
  profileImage,
  profileRadius = 120,
  author = "Cameron McHenry",
  font,
}: GenerateSocialImage) => {
  // ...

  // Draw the author's name
  const authorNameImageSpacing = 25;
  const authorNamePosition = {
    x:
      profileImage === undefined
        ? margin
        : margin + profileRadius + authorNameImageSpacing,
    y: bottomOfTitleText + authorNameHeight / 2,
  };
  ctx.font = `${fontSize}px ${font}`;
  ctx.fillText(author, authorNamePosition.x, authorNamePosition.y);

  // ...
};

If a profile image is passed in, then we position the author's name more to the right, so that there is enough room to draw the profile image. Otherwise, we use the same text drawing call that we used for drawing the title, except this time there is no wrapping.

To see the full code for this article, check out the GitHub Gist.

Creating Social Images from Remix

OK, now that we've figured out how to generate images, the most complex part is over. Now we need to integrate it with Remix, which is the fun part 😊.

Recall from earlier in this post, I said that Remix gives us complete control of the endpoints in our application. The way that we can integrate our social image generation function is via a custom endpoint in our server code, which should be located in app/entry.server.tsx (if you are using a standard Remix template).

Inside of entry.server.tsx there is a handleRequest function which lets us return anything we want whenever. By default it will look something like this:

export default async function handleRequest(
  request: Request,
  responseStatusCode: number,
  responseHeaders: Headers,
  remixContext: EntryContext
) {
  const markup = ReactDOMServer.renderToString(
    <RemixServer context={remixContext} url={request.url} />
  );

  return new Response("<!DOCTYPE html>" + markup, {
    status: responseStatusCode,
    headers: {
      ...Object.fromEntries(responseHeaders),
      "Content-Type": "text/html",
    },
  });
}

We are going to insert some code before we render the DOM, to see if we should generate an image instead. To make this check easier, my social image function endpoint is going to exist at the root of my app under /social-image.

export default async function handleRequest(
  request: Request,
  responseStatusCode: number,
  responseHeaders: Headers,
  remixContext: EntryContext
) {
  const url = new URL(request.url);
  if (url.pathname.startsWith("/social-image")) {
    // TODO: Generate the image!
  }

  const markup = ReactDOMServer.renderToString(
    <RemixServer context={remixContext} url={request.url} />
  );

  return new Response("<!DOCTYPE html>" + markup, {
    status: responseStatusCode,
    headers: {
      ...Object.fromEntries(responseHeaders),
      "Content-Type": "text/html",
    },
  });
}

To generate our image, we just need to the call generateImage with some data relevant to the requested URL and then return a response containing that image.

const url = new URL(request.url);
if (url.pathname.startsWith("/social-image")) {
  const socialImage = await generateImage({
    title: "Generating Social Images with Remix",
    author: "Cameron McHenry",
    profileImage: "assets/images/camchenry.png",
  });
  return new Response(socialImage, {
    headers: {
      "Content-Type": "image/png",
      "Cache-Control": "public, max-age=2419200",
    },
  });
}

Now if we run npm run dev and go to http://localhost:3000/social-image, we should see our image in the browser! 🎉

Changing Fonts

The big thing missing in the code so far is: how do we handle rendering different kinds of fonts? We can set the font correctly with the font property, but since the server will (probably) not have the font installed, it will default to the operating system default font.

So, we need to load the font into the canvas renderer so that it understands our custom fonts. For this example, I will be using the Inter font family.

Once you have the font files you want to use (in a format like OTF or TTF), we can place them adjacent from our application code. In my case, I structure the assets like this:

/
  app/
    entry.server.tsx
  assets/
    images/
    fonts/

To use custom fonts, we need to import the registerFont function from the canvas library. Then, we will load the font files right before we generate the image.

import { registerFont } from "canvas";

registerFont("assets/fonts/Inter-Regular.otf", {
  family: "Inter",
  weight: "400",
});
registerFont("assets/fonts/Inter-Bold.otf", {
  family: "Inter",
  weight: "700",
});

const socialImage = await generateImage({
  title: "Generating Social Images with Remix",
  author: "Cameron McHenry",
  font: "Inter",
  profileImage: "assets/images/camchenry.png",
});

Now if we set the font for generateImage, we should see our custom font in the social image!

Note for Vercel Users

If you are not hosting an application Vercel, you can skip this section.

This section is relevant to people that are hosting their Remix app on Vercel. Unfortunately as of the publishing date of this post there are some common issues related to hosting a Remix app on Vercel and dynamically generating images using the canvas library.

To save you some time, I have listed out all of the Vercel-specific steps I needed to take to get it deployed successfully.

1. Install canvas@2.6.1

If you try to use the latest version of the canvas library, you will likely run into an error about some version of ZLIB not existing. The easiest fix for this is to just downgrade to canvas@2.6.1 for the time being by running:

npm install canvas@2.6.1

2. Add command to install missing packages

There are some missing dependencies in the Vercel container used to run your apps, but they can be installed by adding a vercel-build command to package.json:

{
  "scripts": {
    "vercel-build": "yum install libuuid-devel libmount-devel zlib && cp /lib64/{libuuid,libmount,libblkid,libz}.so.1 node_modules/canvas/build/Release/"
  }
}

3. Add Assets to Serverless Function

The serverless function that gets deployed to Vercel will not include other assets like fonts and images by default, unless you specify them in vercel.json. That means it will look OK on your local machine, but will fail when deployed on Vercel.

To add the assets to our serverless function deployment, we need to specify the files that we would like to include in the builds section in vercel.json. The basic configuration for deploying a Remix app on Vercel looks something like this:

{
  "builds": [
    {
      "src": "public/**/*",
      "use": "@vercel/static"
    },
    {
      "src": "server/index.js",
      "use": "@vercel/node"
    }
  ]
}

To include assets, we can add an extra config for server/index.js:

{
  "src": "server/index.js",
  "use": "@vercel/node",
  "config": {
    "includeFiles": ["assets/**"]
  }
}

Now when our server code is built and deployed, it will also include all files in the assets/ directory.

Conclusion

Social images are a great way to introduce users to a link on your website, before they even click on it. Remix makes dynamically generating images and adding it to your website much simpler compared to other React frameworks. By generating images using the canvas library, we can add lots of dynamic behavior to our images, in combination with the power that Remix gives us to control how it gets accessed and cached.


To see the full code for this article, check out the GitHub Gist.
